Voice Coil Motor Total Trip 20mm Repeat Positioning Accuracy ±1μM No Tooth Groove Effect
Voice Coil Motor Total Trip 20mm Repeat Positioning Accuracy ±1μM No Tooth Groove Effect
* Suitable for high frequency short stroke motion system.
* Direct drive,no tooth groove effect.
* No friction between the mover and the stator.
* Excellent reliability.
| Performance rating | Unit | QY15-L20 |
| Total trip | mm | 20 |
| Peak thrust | N | 20 |
| Continuous thrust (under temperature Tmax) | N | 15 |
| Motor constant (under 25 ℃) | | 7 |
| Voltage | V | 24 |
| Peak current | Arms | 3 |
| Continuous current (under temperature Tmax) | Arms | 1.2 |
| The most powerful | W | 72 |
| Resistance(under 25°C±10%) | Ω | 10 |
| Inductance ±20% | mH | 4.2 |
| potential constant(under25°C±10%) | Vpeak/m/s | 12.8 |
| Thrust constant(under25°C±10%) | N/Arms | 12.8 |
| Rotor coil weight±15% | kg | 0.175 |
| Total weight±15% | kg | 0.85 |
| Maximum allowable coil temperature | °C | 150 |
| Positioning accuracy | um | ±5 |
| Repeat positioning accuracy | um | ±1 |
Outline dimension drawing
Advanced production equipment and modern production management is an important basis for HXC to provide customers with high-quality products, our company widely absorbs the latest technical achievements in the industry, continuous innovation and strive to continuously provide customers with more excellent performance and quality of direct drive motion control solutions.
FAQ:
Q1:Are you a factory or trading company?
A:We are an integrated service company specializing in manufacturing automation equipment and are committed to helping customers improve productivity; the company has strong design and research and development capabilities, production capabilities and excellent service teams, and we have our own brand.
Q2:Can I make a OEM order?
A:We can customize the product you want according to your needs.No matter what your automation requirement it is, you will get the satisfied answer in the cooperation with HXC.
Q3:How does your factory do regarding quality control?
A:”Quality is priority.” Our team always attach great importance to quality controlling from the very beginning to the very end.
Q4:What about you packages?
A:We have been exporting lots of products to overseas,no any clients make any complains on our packages.Please contact us and we will send photos to show you the details of our secure packages.
Q4:What's your payment term?
A:L/C, T/T, Western Union
Product certificate
Factory environment
