18bit General Scanning Galvanometer High Repeatability Galvanometer Scanning Mirror

Shenzhen Haixincheng Technology Co.,Ltd
Contact Now

18bit General Scanning Galvanometer High Repeatability Galvanometer Scanning Mirror

Brand Name : HXC

Model Number : ULTRA-GALVO-S

Certification : CE

Place of Origin : China

MOQ : 10

Price : Negotiable

Payment Terms : T/T, Western Union, L/C

Delivery Time : 5-8 work days

Packaging Details : Conventional packaging or according to customer requirements.

Repeatability : <2

Maximum angle : ±12.5

Position analysis degree : 18bit

Nonlinearity : <0.4

Offset drift : <15

Position resolution : <50

Contact Now

Ultra Galvo Scanner High Repeatability And Linearity With High Cost Performance Ratio

Ultra Galvo Scanner High Repeatability And Linearity With High Cost Performance Ratio

The galvanometer scanner laser using photoelectric sensor as feedback system is characterized by high repetition accuracy and linearity, and high cost performance. Mirror coating film selection is rich, UV, green light, optical fiber, CO2 and other coating options, strict lens quality testing to ensure the requirements of lens flatness and damage threshold, photoelectric mirror is widely used in galvo laser welding, flight marking, precision marking, precision cutting, and other industries.

Key Features Of Ultra-galvo Scanner

  • Through kinematics and dynamics simulation, the mirror with certain inertia is matched for each galvanometer. Moreover, the rotor of the galvanometer has been optimized and has excellent dynamic properties and response characteristics.
  • In addition, high precision miniature bearing axial preloads ensure high rigidity and low friction operation, and special attention is paid to bearing life.
  • Photoelectric galvanometer is a kind of galvanometer which uses photoelectric sensor as feedback system.
  • Galvanometer scanning mirror is available for common laser wavelengths and energy levels. Moreover, all the mirrors are optimized to take into account the inertial load, rigidity and flatness of the lenses.
  • Photoelectric galvanometer is widely used in flight marking, precision marking, precision cutting, precision welding and other industries.

Specifications Of Ultra-galvo Scanner

Ultra Galvo XXXS XXS XS S M L XL
Input Beam Aperture (mm) <7 7 8.5 10 14 20-30 50-80
Moment Of Inertia(g•cm2) 0.013 0.018 0.174 0.34 1.2 5.1 14.3
Force Constant(N•mm/A) 1.2 2.7 5.3 7.5 15 24 35
Coil Resistance(Ω) 2.1 3.6 2.1 2.7 2.6 1.58 0.9
Coil Inductance(µH) 35 70 63.5 165 275 300 343
Maximum Continuous Current(A) 2.3 2.3 2.3 2.5 3.5 5 7
Peak Current(A) 6 8 10 10 10 10 10
Rise Time(ms) 0.13 0.1 0.15 0.18 0.3 0.7 1.5
Weight(g) 13 18 50 220 300 400 460

Galvanometer Application

laser marking,laser welding,laser drilling,laser cutting,micromachining,medical aesthetic,ophthalmic imaging,3D printing,lithum battery

Technical drawing

18bit General Scanning Galvanometer High Repeatability Galvanometer Scanning Mirror

18bit General Scanning Galvanometer High Repeatability Galvanometer Scanning Mirror

18bit General Scanning Galvanometer High Repeatability Galvanometer Scanning Mirror

18bit General Scanning Galvanometer High Repeatability Galvanometer Scanning Mirror

FAQ:


Q: How to order?

A: send us inquiry → receive our quotation → negotiate details → confirm the sample → sign contract/deposit →mass production →cargo ready → balance/delivery → further cooperation

Q:Which shipping way is available?

A: DHL, UPS, FedEx, EMS,Sea are available. The other shipping ways are also available, please contact us if you need ship by the other shipping way.

Q: How long is the deliver Producing and shipping?

A:Deliver time depends on the quantity you order. usually it takes 15-25 working days.

Q: My package has missing products. What can I do?

A: Please contact our support team and we will confirm your order with the package contents.We apologize for anyinconveniences.

Q: How to confirm the payment?

A: We accept payment by T/T, PayPal, the other payment ways also could be

accepted,Please contact us before you pay by the other payment ways. Also 30-50% deposit is available, the balance money should be paid before shipping.
