Small Thrust High Precision EL32 Series Submicron Coreless Kinematic Motor
Low force applications: Force range Fc:11.5-23N, Fp:46-92N
Very compact size, and with extremely high force density
Very Low weight and extremely big force makes the perfect fifit for vertical applications
no attraction force and cogging, high dynamic motion performances
High acceleration, high speed, submicron positioning accuracy and low power consumption
Very good heat dissipation performance
Any length of high flflex chain cables for motors can be made
| Magnet Plate Mounting Dimensions |
| Length (mm) | 72 | 96 | 144 |
| M4 Bolts | 2 | 3 | 4 |
| Weight(Kg/m) | 2.3 |
| MagnetPlates can be jointed together without limits |
| Dig.Hall Sensorconnections |
| 1 | OV | White | 0 |
| 2 | 5~28V | Brown | 0 |
| 3 | Hall A | Green | 0 |
| 4 | Hall B | Yellow | 0 |
| 5 | Hall C | Red | 0 |
| Motor Connections |
| 1 | Phase U | Phase 1 | 0 |
| 2 | Phase V | Phase2 | 0 |
| 3 | Phase W | Phase 3 | 0 |
| 4 | PE | Yellow-Green | 0 |
| Temperature Sensor Connections |
| 1 | PTC 1KΩ | Brown | 0 |
| 2 | PTC 1KΩ | White | 0 |
| 3 | NTC | Yellow | 0 |
| 4 | NTC | Green | 0 |
| Performance Parameters |
| Parameters | Remarks | Symbols | Unit | EL32-03 | EL32-06 |
| Winding Type | | | | S | S |
| Motor Type | 3 phases synchronous lronless,45Vacrms(60Vdc) |
| Peak Forcea20℃/s↑ | Magnet@25℃ | Fp | N | 46 | 92 |
| Continuous Force | Coil@120 ℃ | Fc | N | 11.5 | 23 |
| Maximum Speed | @6ov | Vmax | m/s | 5 | 5 |
| Motor ForceConstant | Mount. sfc@20℃ | K | N/Arms | 7.3 | 7.3 |
| Motor Constant | Coikse25℃ | S | N²/W | 7.5 | 15 |
| |
| Electrical Parameters |
| Peak Current | Magnet@25℃ | lp | Arms | 6.3 | 12.6 |
| Continuous Current | Coil@120 ℃ | lc | Arms | 1.6 | 32 |
| BackEMF | PhasePhase peak | Bemf | V/M/S | 6.0 | 6 |
| Resistance Per Phase | Coila25℃ | Rph | Ω | 2.4 | 1.175 |
| Induction Per Phase | l<0.63lp | Lph | mh | 8 | 4 |
| Electrical Time Constant | Coile25℃ | τe | ms | 0.355 | 0.355 |
| Power Loss | All coils | Pe | W | 240 | 47 |
| |
| Thermal performance parameters |
| Thermal R. | Coils to mount.Sfc. | Rth | ℃/W | 3.2 | 1.6 |
| Temp.Sensor | Temperature Cut-off | NTC Optional |
| |
| Mechanical Parameters |
| Coil Unit Weight | ex.cables | W | kg | 0.04 | 0.08 |
| Coil Unit Length | ex.cables | L | mm | 49 | 97 |
| Motor Attraction Force | Rms@0A | Fa | N | 0 | 0 |
| Magnet Pitch | N-N | τ | mm | 24 | 24 |
| CableMass | | M | kg/m | 0.065 | 0.065 |
| Cable Type(Flex.cable) | length 1m | d | mm(AwG) | 4.5(24) | 4.5(24) |
| Power Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mmtmm²) | 4.5(3*0.3mm²) |
| Sensor CableType | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm²) | Customi Zable |
| Cablelife | Minimum | | Cycles | ≥12,000,000 |
| Bending Radius Static | Minimum | | mm | ≥4xφ |
| Bending Radius Dynamic | Minimum | | mm | ≥7.5xφ |
